Description

Technical Specification

Rope Range 48 mm to 120 mm
Pitch Size 1800 mm
Bobbin Size 950 mm TRA X 750 mm Dia
Strand Bobbin Capacity 180 Kgs
Carriers Type Vertical Bobbin
Braid Length 90 mm to 500 mm
Horn RPM 16Max
Dimension L-14.5 mtr. x W-5 mtr x H-6 mtr. (Horn Asse with Take Up)
Weight of Machine 50,000 Kgs.
Motor Power 13.5 KW

Key Features

  • User Friendly Touch Screen Display.

  • All Parameters will be Shown on Display.

  • Braid Length Adjustment by Display.

  • Meter Set Point for Desired Length.

  • Auto Stoppage at Empty Bobbin.

  • Stepless Variable Synchronized Speed Control.

  • Machine with Fenced Guard.

  • Helical Gear Box.

  • Machine Lubrication Wearing.

  • Daily, Weekly & Monthly report system. (Direct Save in Excel Format)

  • Wi-Fi Connectivity System for Computer.

Optional Features

  • Horn Gear and Horn Flanges are in steel Material

  • Double Stage Foundation Base.

  • Heavy Duty Needle and Trust bearings are in Horn Assembly.

  • Vertical Bobbin Mounting Provision.

  • Heard Chrome Plated Guide Pulleys.
