Description

Technical Specification

MODEL PPI / E-12
ROPE RANGE 12mm to 24mm
STRAND FLYER RPM Max. 500
ROPE FLYER RPM Max. 250
TWIST RANGE 7 to 32 TPM
TWIST PER MINUTE Twice The Flyer Speed
ROPE LAY Z
TWIST IN STRAND Adjustable
PAY OFF PACKAGE SIZE 250 mm Dia. X 300 mm Tra.
TAKE UP CAPACITY 60 Kgs. (Approx)

Key Features

  • Anti twisting unit.

  • User friendly touch screen display with PLC control.

  • All parameters will be shown on display.

  • RPM/TPM & twist factor adjustment by display.

  • Weight & Meter set point.

  • Denier & twisting calculator in display.

  • Door location warning.

  • Machine lubrication warning.

  • A.C. drive fault alarm indication.

  • 100 program memory storage facility.

  • Daily, weekly & monthly report system. (Direct save in excel format)

  • Electrical Take up system

  • Direct Coiling Head

  • Feeding capstan mechanism

  • Wi-Fi connectivity system for computer.

Optional Features

  • Ele.Wire hoist for removal of final package

  • Rope Lay S & Z.

Production Capacity ( On 100% Efficiency )

ROPE SIZE PROD. (KG/HR.) TPM RPM (MAX) GRM/MTR
12mm 87.20 kg 22.52 250 65.45
14mm 138.41 kg 19.31 250 89.09
16mm 206.68 kg 16.89 250 116.36
18mm 264.73 kg 15.02 225 147.27
20mm 363.37 kg 13.51 225 181.82
22mm 429.26 kg 12.29 200 220.00
24mm 417.05 kg 11.26 150 261.82
AVAILABLE MODELS PPI/E-12-360 PPI/E-12-480
Motor Capacity 22 KW 22 KW
Number of Strand 3 Ply 4 Ply
Number of pay off package 20 x 3 = 60 20 x 4 = 80
Dimension (L x W x H) 33′ 5″ x 7’3″ x 7’5″ 33′ 5″ x 7’3″ x 7’5″
Weight (Approx.) 7000 Kgs. 7500 Kgs.
